Description
Specification
| Key Features | |
| Encoding Resolution | When 1080p Lite mode is not enabled: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF |
| Frame Rate | Main stream: When 1080p Lite mode is not enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode is enabled: 4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) |
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Generel information | |
| Dual-Stream | Support |
| Stream Type | Video, Video & Audio |
| Video Bitrate | 32 Kbps to 6 Mbps |
| Network | |
| Remote Connection | 32 |
| Total Bandwidth | 72 Mbps |
| Physical Information | |
| Dimension (WxDxH) | 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch) |
| Audio and Video | |
| Analog Video Input | 4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| Incoming Bandwidth | 24 Mbps |
