Description
Key Features
- Model: NVR4116-4KS3
- Supports IP Cameras with a Resolution Up to 12 MP
- Ai by Recorder Supports 4-Channel Smd Plus
- Max. 160/160/80 Mbps Incoming/recording/outgoing Bandwidth
- Supports Eptz, and One-Click Arming and Disarming
Specification
| System | ||
| Main Processor | Industrial-grade processor | |
| Operating System | Embedded Linux | |
| Audio and Video | ||
| IP Camera Input | 16 channels | |
| Display | ||
| Interface | 1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI | |
| Resolution | 1 HDMI, 1 VGA Simultaneous： HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous： HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 | |
| Decoding Capacity | AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fps AI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fps
AI enabled: 1-channel 32 MP@25 fps; 1-channel 24 MP@25 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 6-channel 8 MP@30 fps; 8-channel 6 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps |
|
| Multi-Screen Display | Main Screen: 1/4/8/9/16 Sub Screen: 1/4/8/9/16 | |
| Recording | ||
| Compression | Smart H.265+; H.265; Smart H.264+; H.264 | |
| Resolution | 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF | |
| Record Mode | General, motion detection; intelligent; alarm | |
| Video Detection And Alarm | ||
| Alarm Input | 4 channels | |
| Playback And Backup | ||
| Playback Function | Instant playback, general playback, event playback, tag playback, smart playback | |
| Backup Mode | USB device and network | |
| Third Party Support | ||
| Third Party Support | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha | |
| Network | ||
| Ethernet Port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) | |
| Network Function | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.) | |
| Storage | ||
| Internal HDD | 1 SATA port. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature. | |
| Auxiliary Interface | ||
| USB | 2 (2 rear USB 2.0 ports) | |
| Power | ||
| Power Supply | 12 VDC, 2 A | |
| Power Consumption | Total output of NVR is <10 W(without HDD) | |
| Component Environment | ||
| Operational Conditions | –10 °C to +55 °C (14 °F to +131 °F) | |
| Storage Conditions | –20 °C to +60 °C (–4 °F to +140 °F) | |
| Construction | ||
| Dimensions | 204.6 mm × 206.4 mm × 45.6 mm(8.06″ × 8.12″ × 1.80″) (W × D × H) | |
| Net Weight | 0.45 kg (0.99 lb) | |
| Gross Weight | 1.07 kg (2.36 lb) | |
| Warranty | ||
| Manufacturing Warranty | 1-year | |
