Description
Key Features:
- 2-MP 1/2.8″ CMOS image sensor,
- Outputs max. 2 MP (1920 × 1080) @25/30 fps.
- H.265 codec, high compression rate, ultra-low bit rate.
- 01-Years Warranty
Specification:
| General | |
| Material | Plastic |
| Operating Conditions | –40 °C to +55 °C (–40 °F to +131 °F) < 95% (non-condensation) |
| Operating Humidity | < 95% (non-condensation) |
| Pan/Tilt/Rotation | Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Power | 12V DC/PoE (802.3af) |
| Power Consumption | Basic power consumption: 1.3 W (12 VDC); 2.1 W (PoE) Max. power consumption (ICR + H.265+IR intensity): 2.9 W (12 VDC); 3.9 W (PoE) |
| Dimensions | 198.9 mm × 80.2 mm × 76.2 mm (7.83″ × 3.16″ × 3.00″)(L × W × H) |
| Weight | Net Weight:- 0.25 kg (0.55 lb) Gross Weight:- 0.40 kg (0.88 lb) |
| Camera | |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Image Sensor | 1/2.8″ CMOS |
| IR Distance | UP to 30 m (98.4 ft) (IR) |
| Minimum Illumination | 0.01 lux@F2.0 (Color, 30 IRE) 0.001 lux@F2.0 (B/W, 30 IRE) 0 lux (Illuminator on) |
| S/N Ratio | > 56 dB |
| Lens | |
| Angle of View | 3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100° |
| Focal Length | 3.6 mm; |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Video | |
| Day/Night | Auto (ICR)/Color/B/W |
| Frame Rate | Main stream:1920 × 1080@1–25/30 fps Sub stream:704 × 576@1–25 fps704 × 480@1–30 fps The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Resolution | 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Warranty Information | |
| Warranty | 01-Years Warranty |
